váz: KELLYS THEOS F-series - Thermoplastic Hybrid Steel-Carbon Composite a.k.a. FEATHERŽ by Rein4ced assembled by advanced robotic manufacturing / Think Link suspension system, 170 mm rear travel, integrated removable battery, 1.8 tapered HT, post mount 203 mm, mullet 29 / 27.5+ wheelset, 12x148 mm Boost thru axle / Designed & manufactured in EUROPE
vázméret: M / L
motor: SHIMANO EP8, 85 Nm, 36 V
switch unit: SHIMANO SW-EM800-L for assist
computer display: SHIMANO SC-EM800
akkumulátor: KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
villa: ROCK SHOX Zeb Select+ (29) Boost, 180 mm, DebonAir / Charger 2.1 RC / Maxle Stealth 15 mm thru axle
hátsó rugóstag: ROCK SHOX Super Deluxe Select R (230x65 mm)
kormánycsapágy: ACROS 1.8 semi-integrated tapered
hajtómű: SHIMANO EM600 (38T) - length 170 mm
váltókarok: SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV)
h. váltó: SHIMANO Deore XT Linkglide M8130 (direct mount)
fokozatok száma: 11
kazettás fogaskoszorú: SHIMANO Linkglide CS-LG600-11 (11-50T)
lánc: SHIMANO Linkglide CN-LG500 (122 links)
fékek: SHIMANO Deore XT M8120 Hydraulic Disc
féktárcsák: 203 mm front / 203 mm rear
fékkarok: SHIMANO Deore XT BL-M8100
kerékagyak: SHIMANO Deore MT410-B / MT400-B Disc Center Lock (32 holes)
rögzített tengely: ROCK SHOX Maxle Stealth 15x110 mm front / Mr.control 12x177 mm rear
felnik: KLS Bender Disc (622x38 front / 584x38 rear / 32 holes)
küllő: stainless steel black
köpenyek: SCHWALBE Eddy Current Evo SuperTrail 65-622 (29x2.60) Tubeless Easy, ADDIX Soft, folding front / SCHWALBE Eddy Current Evo SuperGravity 70-584 (27.5x2.80) Tubeless Easy, ADDIX Soft, folding rear
kormányszár: RACE FACE Aeffect R 35 - diam 28.6 mm / bar bore 35 mm / 0° / length 50 mm
kormány: RACE FACE Chester 35 RiseBar - diam 35 mm / rise 35 mm / width 780 mm
markolat: KLS Poison
nyeregcső: KS Rage-i Remote Telescopic - diam 30.9 mm / length 442 mm, travel 150 mm (M) / length 495 mm, travel 170 mm (L)
nyereg: fizi:k Taiga, S-alloy rails
pedálok: plastic
